UNI-T UT611 LCR Meter

Overview

The UNI-T UT611 LCR Meter is a precision instrument designed for measuring inductance (L), capacitance (C), and resistance (R) in electrical components and circuits. Ideal for both professionals and hobbyists, this LCR meter provides accurate and reliable measurements, making it an essential tool for tasks ranging from component testing to circuit design and troubleshooting.

Features

• High Accuracy: Provides precise measurements with high accuracy, ensuring reliable data for analysis and troubleshooting.
• Wide Measurement Range: Capable of measuring a broad range of inductance, capacitance, and resistance values, making it versatile for various applications.
• Multiple Test Frequencies: Offers different test frequencies to suit a variety of components and measurement requirements.
• Clear LCD Display: Large, backlit LCD screen for easy reading of measurements, even in low-light conditions.
• Auto-Ranging Function: Automatically selects the appropriate range for measurements, simplifying the testing process.
• Data Hold Function: Allows users to freeze the current measurement on the display for convenient reading and recording.
• Portable Design: Compact and lightweight, making it easy to carry and use in different locations.
• Durable Construction: Built with robust materials to withstand frequent use and ensure long-lasting performance.

Specifications

• Brand: UNI-T
• Model: UT611
• Inductance Range: 20µH to 200H
• Capacitance Range: 2pF to 20mF
• Resistance Range: 20Ω to 20MΩ
• Accuracy: ±(0.3% + 1 digit) for resistance, ±(0.5% + 1 digit) for capacitance, ±(0.4% + 1 digit) for inductance
• Test Frequencies: 100Hz, 120Hz, 1kHz, 10kHz
• Display: 1999-count LCD, backlit
• Power Supply: 1 x 9V battery (6F22)
• Dimensions: 175mm x 85mm x 40mm
• Weight: Approx. 325g (including battery)
• Operating Temperature: 0°C to 40°C (32°F to 104°F)
• Storage Temperature: -10°C to 50°C (14°F to 122°F)

Why Choose the UNI-T UT611 LCR Meter?

The UNI-T UT611 LCR Meter is a reliable and efficient tool that provides precise measurements for inductance, capacitance, and resistance. Its high accuracy, wide measurement range, and user-friendly features make it an excellent choice for professionals and hobbyists alike. Whether you are testing components, designing circuits, or troubleshooting electronic systems, this LCR meter delivers the performance and reliability you need.
