Takumi Tool Desoldering Pump

SUPERIOR QUALITY:

1. Large capacity, powerful spring. Simple operation, powerful solder sucker.
2. One-touched cylinder and holder, which are easy to clean.
3. The protector can make you safe to operate it.
4. Cleaned shaft can help the nozzle for remove the solder.
5. Protector-styled load mechanism is convenience to take along.

OPERATION PROCEDURE:

1. Push the set-knob for loading the cleaned shall unit the knob stops.
2. Melt the solder where it is intended to remove.
3. Aim the nozzle to the melted solder and then push the release button. Thus the solder can be sucked.
4. Press the release button while pushing the set knob without reloading the cylinder.
5. Push the set-knob and then pull the protector. The load mechanism is released.

CAUTION:

1. Don’t take down the nozzle mechanically.
2. Don’t let the solder fall in to the nozzle avoiding short-circuit.
3. Don’t use the damage nozzle.

MAINTENANCE:

1. Push the sat-knob until it stops and then take down the nozzle.
2. Stuff the nozzle tint into the cylinder holder, then press it gegtely toward the holder.
3. Grasp the cylinder and shaft holder and turn it anti-clock wise, pull and remove it.
4. Clean the piston and the inner cylinder with a brush and then oil them.
5. Be careful to examine and replace the nozzle if necessary because the nozzle might be damaged if the solder is too hot.
